Baud Rate:300 to 19200 baud
Frequency Range:25 to 60 Hz nominal
Humidity Tolerance:Up to 90% non-condensing
Overvoltage Pickup Level:0 to 1.25 × VT in steps of 0.01
Relay Dimensions:Approx. 18cm W x 16.5cm L x 21.5cm H
Current Inputs:5 A phase current inputs and 1 A zero sequence current inputs
Voltage Inputs:3 voltage inputs
Logic Input States:14 logic input states
Output Relays:8 output relays
Insulation Voltage:300 V
The GE SR750-P5-G1-S1-HI-A20-R is a sophisticated feeder management relay designed for industrial control applications. This advanced relay is equipped with multiple current and voltage input channels, making it ideal for monitoring and controlling distribution feeders. With its robust communication protocol options, including Modbus RTU or DNP 3.0, the relay can seamlessly integrate with existing control systems, ensuring reliable data transmission and real-time monitoring. Its ability to handle up to 90% humidity in non-condensing environments makes it highly resilient in harsh conditions. The relay also boasts a variety of protective features, such as overcurrent protection, under/overfrequency protection, and ground fault protection, providing comprehensive safety for your electrical systems. Its compact dimensions and modular design allow for easy installation in standard 19-inch panels, either individually or alongside other 750 series units. Additionally, when paired with the EnerVista 750 software program, users can leverage graphing, trending, and data export functionalities, enhancing overall system performance and maintenance efficiency.
