Brand:General Electric
Model:DS3800NPPB
Type:Circuit Board
Series:Mark IV
Function:Turbine Control
Material:High-grade FR4 epoxy resin
Inductors:3 large, paired and unpaired
Capacitors:3 green, vertically arranged
Fuses:2 located on the side
Dimensions:L x W x H (mm): 150 x 100 x 25
Weight:0.3 kg
Operating Temperature Range:-40°C to +70°C
The GE DS3800NPPB circuit board is meticulously designed to enhance the performance and reliability of industrial control systems, specifically tailored for the demanding requirements of gas and steam turbine operations.
Featuring three large inductors strategically positioned across the board, this component optimizes energy management and reduces operational noise, contributing to the overall efficiency of the system.
Comprehensive with a total of five integrated circuits, the DS3800NPPB ensures robust data processing capabilities, enabling seamless integration and control within complex industrial setups.
Equipped with two precision-fused components, this circuit board safeguards against power surges and short circuits, protecting critical equipment and ensuring uninterrupted operation.
The presence of various gold-lined jumper pins allows for flexible configuration and customization, facilitating easier maintenance and troubleshooting, thus minimizing downtime and enhancing operational flexibility.
