Operating Voltage:36V DC
Current Rating:20mA per channel
Input Impedance:10MΩ
Output Impedance:50Ω
Operating Temperature Range:-40°C to +70°C
Relay Contacts:SPST (Single Pole, Single Throw)
Number of Channels:8
Communication Protocol:MODBUS
Board Size:85mm x 65mm
Mounting Method:Screw Mount
The GE DS3800HIOA1C1E Input Isolator Board is engineered for precision and reliability, ensuring smooth operation in complex industrial control applications. This board is specifically designed to isolate input signals, preventing ground loops and reducing noise interference.
Featuring a wide voltage range from 6 to 36VDC, it caters to diverse power supply needs. Its robust isolation resistance of ≥10MΩ guarantees high levels of signal integrity and protection against external disturbances.
Operable in extreme conditions, from -40°C to +85°C, this board is ideal for industrial environments where temperature fluctuations are common. With a humidity tolerance of 5% to 95% RH (non-condensing), it maintains optimal performance under varying environmental conditions.
The compact design (125mm x 75mm x 15mm) and versatile connectivity options (1 x RS-232, 2 x Ethernet) facilitate easy integration into existing systems, enhancing efficiency and scalability. The board supports Modbus RTU/TCP protocols, ensuring compatibility with a wide range of industrial communication systems.
Crafted with high-quality materials and rigorous testing, the GE DS3800HIOA1C1E is built to withstand the demands of continuous operation in demanding industrial settings. It comes with comprehensive documentation and technical support for seamless installation and maintenance.
