Product Type:Base Driver Circuit Board
Manufacturer:General Electric
Model Number:531X304IBDANG1, F31X304IBDAMG1
Dimensions:14.4cm x 10.2cm x 1.8cm
Weight:0.2kg
Material:High-grade FR-4 epoxy resin
Operating Temperature Range:-40°C to +85°C
Electrical Specifications:{“Maximum Voltage”:”400V DC”,”Current Capacity”:”20A”,”Power Supply Compatibility”:”AC/DC”}
The GE 531X304IBDANG1 & F31X304IBDAMG1 Base Driver Card Boards are designed for seamless integration into existing industrial control systems, offering unparalleled performance and reliability. These boards are engineered to provide precise control over AC motors, ensuring optimal operation in demanding environments.
Each card comprises identical sections, each housing essential components such as diodes, resistors, condensers, integrated circuits, jumper pins, transistors, metal brackets, and crystal oscillators. These components work in harmony to ensure stable power delivery and efficient motor control.
Notably, the card includes a transformer, vertical pin header connectors, and two parallel heat sinks, facilitating efficient heat dissipation and reliable operation under high load conditions. The inclusion of multiple jumper switches allows for customization to meet specific application requirements.
Manufactured by General Electric, known for its commitment to innovation and quality, these base driver cards adhere to stringent safety and performance standards, including CE and UL certifications. They are specifically tailored for use in GE‘s AC2000 system, ensuring compatibility and ease of integration.
With a compact design and lightweight construction, the GE 531X304IBDANG1 & F31X304IBDAMG1 Base Driver Card Boards are designed for long-lasting durability and minimal maintenance, making them an ideal choice for continuous operation in industrial settings.
