Operating Voltage:1000V DC
Output Current:50A
Operating Temperature Range:-40°C to +70°C
Communication Interface:Profinet
Input Signals:24V DC, 5A max
Dimensions (WxHxD):170mm x 100mm x 30mm
Power Consumption:20W
Certifications:[“CE”,”UL”,”ISO 9001″]
Engineered for unparalleled precision and efficiency, the Allen-Bradley 2098-DSD-HV100-SE is a high-voltage servo drive that offers seamless integration into complex industrial systems. Its robust design ensures reliable operation under extreme conditions, making it a preferred choice for manufacturers seeking high-performance motion control solutions.
With a versatile input voltage range of 230VAC to 480VAC, this servo drive is compatible with a wide array of power sources, ensuring flexibility across various manufacturing processes. The inclusion of an auxiliary power supply further enhances its adaptability, supporting a range of applications from high-speed production lines to heavy machinery operations.
Featuring a maximum power loss of 350 watts, the 2098-DSD-HV100-SE is optimized for efficient energy consumption, contributing to operational cost savings without compromising on performance. The internal shunt resistance of 40 ohms ensures stable current flow, reducing the risk of overheating and enhancing system reliability.
Equipped with state-of-the-art shock resistance capabilities, this servo drive is engineered to withstand harsh industrial environments. It can handle shock forces up to 15g at 11ms half-sine, ensuring uninterrupted operation even in the most challenging conditions.
For ease of integration and system scalability, the Allen-Bradley 2098-DSD-HV100-SE is compatible with the ControlLogix Programmable Automation Controller (PAC) platform and SOFTLogix controllers via the SERCOS protocol. This seamless integration allows for simplified control system design and streamlined automation processes, enabling faster time-to-market for your projects.
