Allen Bradley 1746-NIO4V SLC 500 Analog Input & Output Module

Model Type:Analog Input & Output

Manufacturer:Allen Bradley

Model Number:1746-NIO4V

Number of Channels:2 Inputs, 2 Outputs

Input Range:-20 To 20 V Common Mode Voltage

Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS

Input Current Range:-30 To 30 MA Absolute

Output Range:-10 To 10 V, 1 LSB

Voltage Rating:Overvoltage Protection: 7.5 VAC RMS

Input Current:-10 To 10 VDC, 1 LSB

Current Rating:Backplane: 55 MA

Isolation:Backplane: 500 VDC, Enclosure: Open Type

Display:Status LED

Connection Cables:24 – 14 AWG

Mounting:Chassis

Operating Voltage:24 VDC Plus/Minus 10%

Minimum Output Current:300 MA

Output Ranges:4 – 20 MA, 0 – 20 MA, 0 – 21 MA, 0 – 21.5 MA

    The Allen Bradley 1746-NIO4V module offers high-resolution analog input and output capabilities, ideal for applications requiring precise voltage control in industrial automation.

    With its robust design, this module ensures reliable operation under demanding conditions, delivering accurate data for enhanced process monitoring and control.

    Featuring a backplane current draw of 55 mA, the 1746-NIO4V supports efficient power management and minimizes system-wide energy consumption.

    Its open-type enclosure facilitates easy installation and maintenance, ensuring minimal downtime and maximizing operational efficiency.

    Equipped with a status LED display, the module provides immediate feedback on operational status, enabling quick troubleshooting and proactive maintenance scheduling.
