AB 1746-NI16V Analog Input Modules: Precision Data Acquisition for Industrial Automation

Model Type:SLC500

Model Number:1746-NI16V

Manufacturer(s):Allen Bradley

Number Of Channels:16

Input: Common Mode Voltage Range:Plus/Minus 10.25 V relative to Analog Common Terminal

Type Of Input:Plus/Minus 20 MA, 4 – 20 MA, 0 – 1 MA, 0 – 20 MA, (Maximum) Voltage Input Without Damage: Plus/Minus 8 V between any two signal terminals

Current Rating:Backplane: 125 MA at 5 VDC, 75 MA at 24 VDC, Current Input: Plus/Minus 30 MA

Isolation:500 VAC isolation for 1 sec

Power Rating:Backplane: 2.425 W, Enclosure: Open Type

Temperature Rating:0 – 60 DEG C

Environmental Conditions:5 – 95% non-condensing relative humidity

Shock:30 G

    The AB 1746-NI16V Analog Input Modules are engineered to deliver unparalleled accuracy and reliability in industrial environments. These modules are equipped with advanced signal processing capabilities, ensuring seamless integration with a wide array of control systems.

    Each channel supports various input types including current (4-20 mA, 0-20 mA) and voltage inputs, accommodating diverse measurement requirements without damaging the module. The robust design ensures long-term stability and minimal drift, even under extreme environmental conditions.

    With a common mode voltage range of Plus/Minus 10.25 V relative to the Analog Common Terminal, the AB 1746-NI16V is capable of interfacing with a broad spectrum of sensors and transducers, enhancing system versatility.

    Equipped with an open type enclosure, the modules facilitate easy installation and maintenance. The modular design allows for scalability, enabling users to configure their systems to meet specific application needs, whether it’s a small setup or an extensive network.

    The AB 1746-NI16V Analog Input Modules are part of the comprehensive Allen Bradley SLC500 series, renowned for its reliability and ease of use in industrial automation. They come with built-in ports for EtherNet/IP, DH+, DH-485, or RS-232 communication, providing versatile connectivity options for seamless integration with other Allen Bradley devices and third-party systems.
